Fleming Double Bale Transporter

Please Call for Pricing

The Fleming Agri hydraulic double bale transporter transports and stores bales on their side. It also gives maximum protection to the bale wrap. It meets the demands of the large-scale farmers and contractors. You can fit the double bale transporter to both the front and the back of the tractor allowing you to carry up to 4 bales at one time. This machine works equally well with silage, haylage, hay and straw, wrapped and unwrapped round bales.

Features

  • Large diameter 90mm carrier pipes with domed ends, splayed for better bale protection and easy bale collection
  • Heavy duty main beam with 120mm reinforced structural box frame
  • By lifting the first bale on the hydraulic side, then operating the hydraulic ram, the bale can be raised to give sufficient ground clearance to collect the second bale with ease
  • Bull bar frame for better bale protection
  • Bushed and greased hinge points
  • Independent hydraulic bale elevation
  • 2 lift pins

Specifications

DBHYD
Width2570mmLength1542mm
Height950mmWeight328kg
Tine opening900mmLift pinsCat. 2
